Detailed View
Milling head, angular, right hand chuck for cutter arbor Ø22, external coolant supply
| Part Number | 9.489.179 |
| for | 2 Machines |
| Ratio | 2:1 |
| rpm at Input | max. 6000 rpm |
| rpm at Output | max. 3000 rpm |
| Torque at Output | max. 36 Nm |
| Direction of Rotation |  |
| Scope of Delivery | supplied with wrench, clamping bolt, driver ring * Actual size inscribed on the tool |
Additional CAD Files:
2D-View
3D-View
2D-View
